Install SAS Storage Drive Cables
Note - Cable part number 7064129 is required for SAS connections between the front storage
drive backplane and rear storage drive backplane.
3.
Return the server to operation.
a.
Install the server's front fan assembly door cover.
See “Install the Fan Assembly Door” on page 163.
b.
Lower the air baffle to the installed position.
122 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
