Install a DIMM
80 SPARC T5-4 Server Service Manual • July 2016
3.
Unpack the replacement DIMMs and place them on an antistatic mat.
4.
Ensure that the ejector tabs on the connector that will receive the DIMM are in
the open position.
5.
Align the DIMM notch with the key in the connector.
Caution - Ensure that the orientation is correct. The DIMM might be damaged if the orientation
is reversed.
6.
Push the DIMM into the connector until the ejector tabs lock the DIMM in place.
If the DIMM does not easily seat into the connector, check the DIMM's orientation.
7.
Repeat Step 4 through Step 6 until all new DIMMs are installed.
