Error
I11 T11 192-120101 N6 - March 2004 97
Measure:
Increase automatic commutation starting current, eliminate motor block,
check parameters for motor current (too small, device extremely under-
dimensioned), current controller unstable.
Note:
It was not possible to successfully complete automatic commutation within
30 s.
Error code (hex):
0x73AC
Error:
Automatic commutation: mo motor connected
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Connect motor resp. check wiring
Note:
Current controller setting full voltage without current flowing.
Error code (hex):
0x73B0
Error:
Distance coding: invalid position of reference mark
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Note:
Error code (hex):
0x8120
Error:
CRC error or passive mode (CAN)
Error reaction:
None
Measure:
Note:
Field bus error: adjustable reaction (no, reaction 2)
Error code (hex):
0x8121
Error:
Bus off (CAN)
Error reaction:
None
Measure:
Note:
CAN Bus inactive status
Field bus error: adjustable reaction (no, reaction 2)
Error code (hex):
0x8130
Error:
FB Timeout
Error reaction:
None
Measure:
Check connection and master
Note:
Field bus communication failure
Field bus error: adjustable reaction (none, reaction2)
Error code (hex):
0x8181
Error:
Invalid velocity
Error reaction:
None
Measure:
Reduce setpoint value
Note:
Preset speed ins too high (also externally); command was rejected
Error code (hex):
0x8182
Error:
Error CAM command
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Note:
Error code (hex):
0x8183
Error:
Watchdog test movement
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Acknowledge Error occurs for example if the response times of the PC are
too long for RS232 communication.
Note:
Error is triggered if o40.3=0. Watchdog cannot be deactivated via o40.3=-1.
Watchdog time=o40.3*100ms
Error code (hex):
0x8612
Error:
Reference Limit
Error reaction:
Reaction 2: downramp / apply brake / deenergize.
Measure:
Reference position could not be accessed. One of the limit switches was
detected twice. There was no home switch or feedback zero pulse. Homing
was aborted
Note:
No reference point for machine zero detected within the travel range. The
homing sequence was aborted. Check reference point feedback.
0x73AC
0x73B0
0x8120
0x8121
0x8130
0x8181
0x8182
0x8183
0x8612
