Communication
192-120114 N5 C3I22T11 June 2008 331
1127 1 C3Plus.SPEED_accel Acceleration / deceleration in speed
control operating mode
U32 Imme-
diately
1127 3 C3Plus.SPEED_speed Target speed in speed control operating
mode
C4_3 Imme-
diately
1128 1 C3Plus.JOG_accel Acceleration for JOG +/- U32 Imme-
diately
1128 2 C3Plus.JOG_jerk Jerk for Manual +/- U32 Imme-
diately
1128 3 C3Plus.JOG_speed Speed for Manual +/- C4_3 Imme-
diately
1130 1 C3Plus.HOMING_accel Acceleration / deceleration homing run U32 Imme-
diately
1130 3 C3Plus.HOMING_speed Speed for machine reference run C4_3 Imme-
diately
1130 4 C3Plus.HOMING_mode Adjusting the machine reference mode U16 Imme-
diately
1130 5 C3Plus.HOMING_home_offset Machine reference offset C4_3 Imme-
diately
1130 7 C3Plus.HOMING_edge_sensor_distance Initiator adjustment C4_3 Imme-
diately
1130 13 C3Plus.HOMING_edge_position Distance MN (zero) initiator - motor zero C4_3 Imme-
diately
1141 10 C3Plus.GEAR_FFW_mode Control bits for feedforward with source
CANSync/EthernetPowerLink
U16 Imme-
diately
1211 13 C3Plus.PG2POSITION_direction Manipulation of the motion direction in
reset mode
I32 Imme-
diately
1900 1 C3Array.Pointer_Row Pointer to table row U16 Imme-
diately
1901 1 C3Array.Col01_Row01 variable Column 1 Row 1 Y4 Imme-
diately
1902 1 C3Array.Col02_Row01 variable Column 2 Row 1 Y2 Imme-
diately
1903 1 C3Array.Col03_Row01 variable Column 3 Row 1 I16 Imme-
diately
1904 1 C3Array.Col04_Row01 variable Column 4 Row 1 I16 Imme-
diately
1905 1 C3Array.Col05_Row01 variable Column 5 Row 1 I16 Imme-
diately
1906 1 C3Array.Col06_Row01 variable Column 6 Row 1 I32 Imme-
diately
1907 1 C3Array.Col07_Row01 variable Column 7 Row 1 I32 Imme-
diately
1908 1 C3Array.Col08_Row01 variable Column 8 Row 1 I32 Imme-
diately
1909 1 C3Array.Col09_Row01 variable Column 9 Row 1 I32 Imme-
diately
1910 1 C3Array.Indirect_Col01 Indirect table access Column 1 Y4 Imme-
diately
2010 1 C3.FeedForward_Speed Velocity feed-forward U16 VP
2010 2 C3.FeedForward_Accel Acceleration feed-forward U16 VP
2010 4 C3.FeedForward_Current Current feed-forward U16 VP
2010 5 C3.FeedForward_Jerk Jerk feed-forward U16 VP
2010 20 C3.FeedForward_EMF EMC feedforward U16 VP
2011 1 C3.FeedForwardExternal_FilterSpeed External Speed Feed Forward Filter
Time Constant
U16 VP
2011 2 C3.FeedForwardExternal_FilterAccel External Acceleration Feed Forward
Filter Time Constant
U16 VP
2011 4 C3.FeedForwardExternal_FilterSpeed_us Filter time constant ext. Velocity U16 VP
2011 5 C3.FeedForwardExternal_FilterAccel_us Filter time constant ext. Acceleration U16 VP
2020 1 C3.ExternalSignal_Position Position from external signal source C4_3 -
2020 6 C3Plus.ExternalSignal_Speed_Munits Speed value of the external signal
source
C4_3 -
2020 7 C3Plus.ExternalSignal_Accel_Munits Acceleration of the external signal
source
I32 -
2100 2 C3.ControllerTuning_Stiffness Stiffness (speed controller) U16 VP
2100 3 C3.ControllerTuning_Damping Damping (rotation speed controller) U16 VP
2100 4 C3.ControllerTuning_Inertia Moment of Inertia U16 VP
