Specifications
C3I22T11
400 192-120114 N5 C3I22T11 June 2008
Motors and feedback systems supported
Motors
Direct drives
 Linear motors
 Torque motors
 Sinusoidal commutated synchronous motors
 Maximum rotating field frequency: 1,000Hz
 Max. velocity at 8 pole motors: 15000min
-1
.
 General max. speed:
60*1000/number of pole pairs in [min
-1
].
 Max. number of poles = 600
 Sinusoidal commutated asynchronous motors
 Maximum rotating field frequency: 1,000Hz
 Max. speed: 60*1000/number of pole pairs - slip
in [min
-1
].
 Field suppression: typically up to triple (higher
on request).
 Temperature sensor: KTY84-130
(insulated according to EN60664-1 or IEC60664-
1)
 3 phase synchronous direct drives
Position encoder (Feedback)
Option F10: Resolver Feedback
LTN:
 JSSBH-15-E-5
 JSSBH-21-P4
 RE-21-1-A05
 RE-15-1-B04
Tamagawa:
 2018N321 E64
Siemens:
 23401-T2509-C202
Option F11: SinCos
©
 Singleturn (SICK|Stegmann)
 Multiturn (SICK|Stegmann) Absolute position up
to 4096 motor revolutions.
 Rotary feedback with HIPERFACE
®
interface:
e.g.: SRS50, SRM50, SKS36, SKM36, SEK52

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
