Compax3 device description C3I22T11
84 192-120114 N5 C3I22T11 June 2008
Compax3 devices disabled by:
Channel 1: Energize deactivated by PLC due to open contacts of the Emergency
power-off module (13 -14)
Channel 2: Enable input to "0" through open contacts of Emergency power-off mo-
dule (57 - 58)
Activate Emergency power-off module
Before the Compax3 can be placed in operation, the Emergency Power-off module
must be activated by a pulse to Input S33/S34.
Prerequisite:
S3 closed
Safety door closed: only in this case the safety door monitor enables the emer-
gency power off module via two channels
K1 energized via PLC (feedback channel 1: motor not energized)
The feedback contact of all Compax3 devices must be closed (channel 2).
If S33 & S34 of the Emergency power-off module are briefly connected (pulse) the
contacts will be closed (between 13 & 14 and between 57 & 58).
Energize Compax3 (Motor and power output stage)
The PLC enables the Compax3 devices by means of the control word and the
Emergency power-off module enables the Compax3 devices by means of the
Enable input. (if an error is still pending on Compax3, it must be previously
acknowledged/reset)
The motors are energized with current.
Summary: Compax3 is only energized if the feedback functions are capable of
functioning via two channels.
Switches and buttons:
S1: Closed when the safety door is closed
S2: Closed when the safety door is closed
S3: Activate Emergency power-off module
S4: Guide Device 1 to a currentless state (error acknowle-
dge)
S5: Guide Device 2 to a currentless state (error acknowle-
dge)
