Parker Compax3 User Manual

Parker EME
Setting up Compax3
192-120113 N08 C3I12T11 - December 2010
117
MN-M 7...10: Direction reversal switches on the positive side
Machine zero modes with a home switch which is activated in the middle of the
travel range and can be deactivated to both sides.
7
8
9
10
8
10
7
10
9
9
7
8
1
2
3
1: Motor zero point
2: Logic state of the home switch
3: Logic state of the direction reversal switch
MN-M 11...14: With direction reversal switches on the negative side
Machine zero modes with a home switch which is activated in the middle of the
travel range and can be deactivated to both sides.
14
14
14
13
13
13
12
12
12
11
11
11
1
2
3
1: Motor zero point
2: Logic state of the home switch
3: Logic state of the direction reversal switch
With motor zero
point, with direction
reversal switches
With motor zero
point, with direction
reversal switches

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
