Parker Compax3 User Manual

Setting up Compax3
C3I12T11
170
192-120113 N08 C3I12T11 - December 2010
Functions:
 Select background color:Adapt background color to personal requirements.
 Select grid color:Adapt grid color to personal requirements.
 Memorize OSCI settings in file: The settings can be memorized in a file on any
drive. The file ending is *.OSC.
 The format corresponds to an INI file and is presented in the appendix.
 Open OSCI settings from file:Loading a memorized set of settings. The file
ending is *.OSC.
 Memorizing OSCI settings in the project:Up to four sets of OSCI settings can
be memorized in the current C3 ServoManager project. .
 Open OSCI settings from project:If settings were memorized in the project,
they can be read in again.
 Memorize OSCI measurement in file:Corresponds to memorizing the setting;
the measurement values of the measurement are stored in addition. Thus it is
possible to memorize and read measurements completely with settings. The file
ending is *.OSM.
 Export measure samples to csv file:e.g. for reading into Excel.

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
