Parker Compax3

Parker EME
Setting up Compax3
192-120113 N08 C3I12T11 - December 2010
215
Symbol Description
p
K
Proportional term
signal is multiplied with K
p
T1
First order delay component (P-T1 term)
K
I
Integration block (I-block)
Kp,T
N
PI-block
Limitation block (signal limitation)
f
f
B
d
Notch filter (band elimination filter)
Addition block
blue
description
Optimization objects
(simple pointer line)
red
description
Status objects
(pointer line with vertical stroke)
