Setting up Compax3
192-120113 N08 C3I12T11 - December 2010
255
 The motion range monitoring is especially important during current step
responses, as position as well as speed control are deactivated during the
measurement.
Max permitted speed
When exceeding this value, an error is triggered, the controller decelerates and
reports an error.
When measuring the velocity setpoint jerk, the maximum permitted velocity is set to
twice the step height.
Setting and automatic start of the oscilloscope:
After pressing "accept entries", the parameters of the oscilloscope (such as
scanning time and the assignment of the individual channels) are automatically set
to default values according to the respective step value.
When starting the step function, the oscilloscope is automatically started.
Start of the measurement
The start of the step function is made with the aid of the highlighted button.

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
