Parker Compax3

Parker EME
Technical Characteristics
192-120113 N08 C3I12T11 - December 2010
373
Mains connection PSUP10D6
Device type PSUP10
230V
400V
480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
22Arms 22Arms 18Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
6kW 10 kW 10 kW
Pulse power (<5s)
12kW 20kW 20kW
Power dissipation
60W 60W 60W
Maximum fuse rating per
device (=short circuit rating)
Measure for line and device protection:
MCB miniature circuit breaker (K characteristic) 25A in
accordance with UL category DIVQ
Recommendation: (ABB) S203UP-K 25(480VAC)
Mains connection PSUP20D6
Device type PSUP20
230V
400V
480V
Supply voltage
230VAC ±10%
50-60Hz
400VAC ±10%
50-60Hz
480VAC ±10%
50-60Hz
Rated voltage
3AC 230V 3AC 400V 3AC 480V
Input current
44Arms 44Arms 35Arms
Output voltage
325VDC ±10% 565VDC ±10% 680VDC ±10%
Output power
12kW 20kW 20kW
Pulse power (<5s)
24kW 40kW 40kW
Power dissipation
120W 120W 120W
Maximum fuse rating per
device (=short circuit rating)
2 circuit breakers in line are
required
Cable protection measure:
MCB (K characteristic) with a rating of 50A / 4xxVAC
(depending on the input voltage)
Recommendation: (ABB) S203U-K50 (440VAC)
Device protection measure:
Circuit breakers 80A / 700VAC per supply leg in
accordance with UL category JFHR2
Requirement: Bussmann 170M1366 or 170M1566D
