Technical Characteristics
C3I12T11
374
192-120113 N08 C3I12T11 - December 2010
Mains connection Compax3HxxxV4 3*400VAC
Device type Compax3
H050V4 H090V4 H125V4 H155V4
Supply voltage
Three-phase 3*400VAC
350-528VAC / 50-60Hz
Input current
66Arms 95Arms 143Arms 164Arms
Output current
50Arms 90Arms 125Arms 155Arms
Maximum fuse rating per
device(=short circuit
rating)
Branch circuit protection
according to UL
80A 100A 160A 200A
JDDZ Class K5 or H
JDRX Class H
Mains connection Compax3HxxxV4 3*480VAC
Device type Compax3
H050V4 H090V4 H125V4 H155V4
Supply voltage
Three-phase 3*480VAC
350-528VAC / 50-60Hz
Input current
54Arms 82Arms 118Arms 140Arms
Output current
43Arms 85Arms 110Arms 132Arms
Maximum fuse rating per
device(=short circuit
rating)
Branch circuit protection
according to UL
80A 100A 160A 200A
JDDZ Class K5 or H
JDRX Class H
Control voltage 24VDC Compax3S and Compax3H
Controller type
Compax3
Voltage range
21 - 27VDC
Current drain of the device
0.8 A
Total current drain
0.8 A + Total load of the digital outputs + current
for the motor holding brake
Ripple
0.5Vpp
Requirement according to safe extra
low voltage (SELV)
yes
Short-circuit proof
conditional (internally protected with 3.15AT)
Control voltage 24 VDC PSUP
Device type PSUP
Voltage range
21 - 27VDC
Ripple
0.5Vpp
Requirement according to safe extra
low voltage (SELV)
yes (class 2 mains module)
Current drain PSUP
PSUP10: 0.2A
PSUP20 / PSUP30: 0.3A
Electric current drain Compax3M
C3M050D6: 0.85
3M100D6: 0.85A
C3M150D6: 0.85A
C3M300D6: 1.0 A
+ Total load of the digital outputs + current for
the motor holding brake

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
