Software Reference 106
P/N CLS151164 Rev. B LabChip GX Touch/GXII Touch User Manual PerkinElmer, Inc.
Select Wells to View Tab
Use the Select Wells to View tab to select the wells to view in the
graphs in the Egram/Gel Tab and EGram Tab. Select the Overlay
check box to select multiple wells. To open the Select Wells to View
Tab, touch the Views button on the Navigation Bar and then touch
the Select Wells button.
Figure 40. Select Wells to View Tab
Overlay check box - If selected, multiple wells can be selected for
view. If not selected, only a single well can be selected for view.
Cycle - If Plate Cycles is greater than one, displays the cycle of the
selected well. Does not display if Plate Cycles equals one.
Perform Sample Analysis check box - If selected, the analyzed
data displays in the Egram/Gel Tab, EGram Tab, and Gel Tab. If not
selected, the raw data displays.
Review Plate button - Opens a data file to view the data. If a data
file is already open, touch the OK button in the Review Plate window
to clear the current plate data. Select the desired data file to open in
the Select a Data File window and then touch the Open button.
Export Plate button - Exports the plate data using the settings in
the Export Settings Tab in the Tools Window. If Peak Table or Well
Table are selected for export, the exported table columns are
selected in the Export Setup Tab in the Tools Window.
