Troubleshooting and Diagnostics 154
P/N CLS151164 Rev. B LabChip GX Touch/GXII Touch User Manual PerkinElmer, Inc.
Description of Instrument Diagnostic Tests
This section includes the following information about the diagnostic
tests: the test names, descriptions, potential failures, and the chip
required to run the test. Touch the Limits Report button to display
the limits for each diagnostic test.
• Computer Resources Test on page 154
• System Components Test on page 155
• Chip Interface Test on page 155
• RF Tag Test on page 156
• Pressure Leak Test on page 156
• Chip Temperature Test on page 156
• Current Leakage Test on page 157
• Laser Test on page 157
• Plate Handler Test on page 157
• Optics Test on page 158
• HV Voltage Calibration Test on page 159
• HV Current Calibration Test on page 159
• Barcode Test on page 159 (if the instrument is equipped with a
barcode reader)
Computer Resources Test
Any chip can be loaded
Description Potential Cause of Failure
Memory Check Available memory below 500 MB. System
may function with lower memory but
there is risk of failure if analyzing many
plates.
Disk Space Check Available disk space below 4 GB. Risk of
losing data as disk space is used. Free
up space on local hard drive.
