Software Reference 71
P/N CLS151164 Rev. B LabChip GX Touch/GXII Touch User Manual PerkinElmer, Inc.
Navigation Bar
The Navigation Bar on the left side of the LabChip GX Touch Main
Window provides access to the main functions of the LabChip GX
Touch software. Touching a navigation button opens the
corresponding window.
The Navigation bar contains the following buttons:
Home button - Opens the Home Window to start a prime,
calibration, pressure line purge, run, or wash operation or
to load/unload plates or chips.
Status button - Opens the Status Window to view the
current status of the instrument, chip, and run. For Protein
Clear HR and ProteinEXact assays, the status of
prime/calibration displays.
Views button - Opens the Views Window to view data from
the last completed run. After a new run is started or the
software is closed, data from a completed run is no longer
available in the LabChip GX Touch software. Use the
LabChip GX Reviewer software to view or analyze data
from previous runs.
Tools button - Opens the Tools Window to add plates, run
software and hardware diagnostics, select Auto export
options, calibrate the optics, or access PerkinElmer service
engineer software functions.
Exit button - Closes the LabChip GX Touch software.
Error button - Only displays if an error has occurred. Opens the
Current Events Tab to view the error details and to clear the error.
Warning button - Only displays if a Warning has occurred. Opens
the Current Events Tab to view the warning details and to clear the
warning.
Stop button - Stops the current operation in progress. If running a
plate, the run stops immediately and the current well does not finish
reading. Any data collected from the current well is discarded. If
priming or washing a chip, the prime or wash stops immediately.
