Exporting Data 45
P/N CLS151164 Rev. B LabChip GX Touch/GXII Touch User Manual PerkinElmer, Inc.
Export Examples (Continued)
Below is an example of part of a raw data CSV file, including size
data, exported from a DNA assay. In this example, the header is not
included and data is truncated.
DATA
Time,Value,Size
0.000,-1.097,0
0.017,-1.512,0
0.033,-1.913,0
...
12.933,19.774,14
12.950,19.836,16
12.967,20.165,19
12.983,20.761,21
13.000,21.384,23
13.017,21.498,25
…
Gel
Exports the gels in the selected image format. Options are available
to export all gels into the same image file or into a separate file for
each gel. The Height selector on the Export tab determines the
height, in pixels, of the exported graphic.
Figure 9 shows all gels exported to one image file.
Figure 9. Exported Gels
