THE NEW PIPER AIRCRAFT, INC.
PA-32-301FT / 301XTC
MAINTENANCE MANUAL
PAGE 4
Jun 1/03
3D10
28-40-00
Tolerance
Switch Position** Required Gauge (Plus or Minus) Resistance (Ohms)
Reading Needle Widths*
F 0 +0, -1/2 5
E 10 ± 1/2 21
D 20 ± 1/2 32
C 30 ± 1/2 46
B 40 ± 1/2 63
A F ± 1/2 90
** See Figure 3 * See Figure 2
CHART 2
FUEL QUANTITY GAUGE BENCH TEST TOLERANCES
