Pitney Bowes Connect+ 1000 - Your Systems Specifications

Connect+® Series Operator Guide
Your System's Specifications
System Dimensions and Weights
Connect+® 1000
l
49.5" L x 22.5" D (1257mm x 635mm) with drop
stacker
l
Power stacker adds 31" (483mm) to length
l
Color adds 6.5" (185mm) to length
l
110 lbs. (49.9kg)
Connect+® 2000
l
65" L x 22.5" D (1638mm x 635mm) with drop stacker
l
Power stacker adds 31" (483mm) to length
l
Color adds 6.5" (185mm) to length
l
150 lbs. (68kg)
Connect+® 3000
l
73.5" L x 25.5" D with drop stacker
l
Power stacker adds 31" (483mm) to length
l
Color adds 6.5" (185mm) to length
l
165 lbs. (74.8kg)
All systems are 24" (610mm)high with base touchscreen display.
Power and Compliance
Power 100-240Vac, 50/60Hz., 6.4 - 3.0 Amps
Compliance Optional ENERGY STAR®
NOTE: Refer to How to Set System Timeouts for infor-
mation about the optional ENERGY STAR sleep
mode.
16
SV62250 Rev. G
