Chapter 3
Reviewing the Mail Piece Specifications
Envelope Dimensions
Minimum 3.5 in. x 5 in. (88.9mm x 127mm) postcard size
Maximum Connect+® 1000 and Connect+® 2000: 13 in. x
14 in. (330 mm x 356 mm)
Connect+® 3000: 15 in. x 15 in. (381 mm x 381
mm)
Envelope Thickness
Minimum Connect+® 1000 and Connect+® 2000: 0.18 in.
(0.007 mm)
Connect+® 3000: 0.09 in. (0.004 mm)
Maximum Connect+® 1000 and Connect+® 2000: 0.625 in.
(15.9 mm)
Connect+® 3000: 0.75 in. (19.1 mm)
Envelope Flap Depth for Sealing
Minimum 1 in. (25.4 mm)
Maximum Connect+® 1000 and Connect+® 2000: 3 in.
(76.6 mm)
Connect+® 3000: 3-7/8 in. (98 mm)
l
For envelopes with a flap length from 1 to 2.36 inches (25 mm to 60 mm), the minimum
flap angle is 18 degrees.
l
For envelopes with a flap length greater than 2.36 inches (60 mm) to the maximum flap
length for the particular model, the minimum flap angle is 21 degrees.
47
SV62250 Rev. G
