UM-PRORUNNER_Mk5-1.2-EN-US 131
Exploded views of frame parts
Tensioning section parts list 2/2
/i
Tensioning section Package A-01-2
Item no. 1000142
Pos Quan-
tity
Item
number
Description (parts) Notes
A 1 1000815 Tensioning section L = 1475 mm
1 1000818 Tensioning section L = 1725 mm
1 1000854 Tensioning section L = 1975 mm
J 2 1000103 Chain guide profile L = 480 mm
2 1000104 Chain guide profile L = 730 mm
1000105 Chain guide profile L = 980 mm
K 2 1000106 Chain guide profile L = 250 mm
L 1 1000055 Curve frame bottom Z = 76
N 3 1000214 Trolley
3 1000820 Trolley HD
O 1 1000094 Baffle plate bottom Z = 76
U 1 1000736 Cable guide side
1 1000752 Cable guide side
1 1000756 Cable guide side
V 1 1000088 Cable guide centre
1 1000089 Cable guide centre
1 1000091 Cable guide centre
W1 2 1000932 Inductive sensor
W2 2 1001326 Prefab cable PVC-OB L = 5 m
2 1001528 Prefab cable PVC-OB L = 2 m
2 1001599 Prefab cable PVC-OB L = 5 m UL CSA
2 1001600 Prefab cable PVC-OB L = 10 m
2 1001601 Prefab cable PVC-OB L = 1 m
X 1 1000723 Exact 12 4 x M12
1 1000903 Exact 12 8 x M12
Y1 2 1000117 Wheel guide coupling plate
Y2 2 1000118 Inner column coupling plate
Y3 2 1000119 Outer column coupling plate
Y4 2 1000129 Nut plate M10 st. 50 mm
Z Assemble these parts at a later stage
