Exploded views of frame parts
132 UM-PRORUNNER_Mk5-1.2-EN-US
Mounting materials tensioning section 2/2
/i
Tensioning section Package A-02-2
Item no.: 1000142
Quan-
tity
Article number Description (mounting mat.) Notes
10 1000134 Allen bolt M12 x 120
8 1000177 Hexagonal socket bolt M10 x 25
4 1000209 Hexagonal nut M16
2 1001175 Hexagonal nut M20
4 1000198 Hexagonal stud bolt M12 x 25
10 1000398 Spring washer M12
12 1000149 Washer M12
6 1000050 Hexagonal stud bolt M8 x 16
4 1000193 Hexagonal stud bolt M8 x 25
16 1000194 Spring washer M8
4 1000195 Washer M8
24 1000172 Locknut M8
12 1000125 Hexagonal stud bolt M8 x 45
20 1000147 Hexagonal stud bolt M10 x 25
4 1000208 Hexagonal stud bolt M10 x 70
4 1000174 Hexagonal stud bolt M10 x 130
3 1001677 Spring washer M10
3 1001676 Nut M10
3 1001675 Washer M10
4
*
* Assemble these parts at a later stage
1000973 Spring washer M6
24 * 1000167 Countersunk bolt M6 x16
