REMOTE KVM CONSOLE ESMS FUNCTIONAL SPECIFICATION
4-5
4. Click Submit button to save changes.
Figure 4-7. Network Configuration window
Remote KVM Console
AST2300 encrypts and compresses video output then sends it to remote PC console. The
Java Remote KVM receives and display server's video screen. AST2300 can acquire video
source either from PCI bus in VGA mode or from external source in Video mode. Refer to
hardware specification for more details about mode switching.
The following lists video screen redirection specification:
\
Console Option
Below is a list of console functions:
Table 2: Video Screen Specification
SPECIFICATION
Frame Resolution Up to 1600x1200 @ 60Hz.
Frame Frequency Up to 85Hz for other resolutions.
Frame Transfer Rate More than 30 frames per second for generic operation.
