INSTALLING HARDWARE REMOVING A MEMORY MODULE
2-18
Removing a Memory Module
1. Power off the sled tray by sliding the sled tray out of the chassis. See Releasing the
Sled Tray on page 2-2.
2. Place the sled tray on a clean work space.
3. Remove the air duct. See Removing an Air Duct on page 2-4.
4. Press down on the two ejector levers at both ends of the DIMM slot. The memory
module partially ejects.
5. Hold the DIMM module by the ends and remove it from the system. Place the DIMM
module in an antistatic packaging.
Figure 2-23. Removing a Memory Module
Installing a Memory Module
1. Locate the DIMM slot to populate and open the ejector levers at both ends of the
DIMM slot.
2. Align the notch on the DIMM module with the protrusion on the slot.
Memory modules remain hot after the system is powered down. Allow sufficient time for the
memory modules to cool before handling system components.
