LED DEFINITIONS ABOUT THE SYSTEM
1-9
Fan LED
The system supports six hot-swap fan modules connected through the midplane board.
The fan module LEDs are located on each fan module, see the following illustration.
Figure 1-8. Fan Module LED
Table 9: Fan LED Definition
LED STATUS DESCRIPTION
Fan LED
Blue Fan failure
Off No failure
fan LED location
