QUANTA Rackgo X Series F03A User Manual

ABOUT THE SYSTEM SYSTEM OVERVIEW
1-4
System Front View
Figure 1-2. System Front View
System Rear View
Figure 1-3. System Rear View
Table 3: Rear Panel View
NO.NAME DESCRIPTION
1
Bus bar connector
assembly
Bus bar connector assemblies for power input (x3)
2 Air grill Air grills for heat discharge (x6)
3Fan module
Fan modules are located inside the air grills. See Fan Module on page 2-
6
compute node 1 compute node 3
compute node 4compute node 2
1 2 3

QUANTA Rackgo X Series F03A Specifications

General

Brand	QUANTA
Model	Rackgo X Series F03A
Category	Server
Language	English
