QUANTA Rackgo X Series F03A User Manual

INSTALLING HARDWARE PROCESSORS
2-26
2.9 Processors
Removing a Processor
1. Pull the locking lever of the processor socket out and up as shown.
Figure 2-35. Releasing the Locking Lever
2. Pull the locking lever at the other side as shown below.
Figure 2-36. Lifting Processor Load Plate
Note:
All the instructions and images in this section are for illustration purposes only and may not
reflect the actual product.
WARNING!
The processor remains hot after the system has been powered down. Allow sufficient time to
cool before handling system components.
!
