QUANTA Rackgo X Series F03A User Manual

IPMI LAN COMMANDS ESMS FUNCTIONAL SPECIFICATION
4-13
Table 7:
PARAMETER #PARAMETER DATA
LAN Mode selection 194
Data 1 - Mode Selection
Mode 1 : BMC will not deal with the VLAN ID field.
Mode 2 & 3 : The range of VLAN ID is from 1 to
4094.
Note:
 In the mode 3, Java Remote KVM application
only will connect to the IP with VLAN ID.
 Must re-open the Java Remote KVM applica-
tion after change the LAN Mode or VLAN ID.
[7:3] - Reserved
[2:0] - Mode Selection (1~3)
 1h = LAN only
 2h = VLAN only
3h = LAN and VLAN co-exist
Data 2 - VLAN ID [7:0] - Least significant 8-bits of the VLAN ID
Data 3 - VLAN ID
[7:4] - Reserved
[3:0] - Most significant four bits of the VLAN ID
LAN and VLAN IP
address
(Read Only)
195
data 1 - LAN type
1h = LAN
All other = reserved
data 2 - 5 :
LAN IP Address
MS-byte first
data 6 - LAN type
2h = VLAN
All other = Reserved
data 7 - 10 :
VLAN IP Address
MS-byte first
