REGULATORY AND COMPLIANCE INFORMATION PRODUCT REGULATORY COMPLIANCE MARKINGS

7-5

Recycling Package Mark

Other than

China

EAC Marking Russia

Table 1: Product Regulatory Compliance Markings (Continued)

REGULATORY COMPLIANCE REGION MARKING
