QUANTA Rackgo X Series F03A User Manual

ABOUT THE SYSTEM INTRODUCTION
1-2
* All specifications and figures are subject to change without prior notice.
PCIe Expansion Slot
 SKU 1: (2) PCIe x8 G3 riser slots for low-profile card per node
 SKU 2: (1) PCIe x8 G3 riser slots for low-profile card per node
 Both SKU 1 and SKU 2 have (1) PCIe x8 G3 dedicated OCP network mezzanine
card slot per node
SW RAID Options
 Intel® C602 upgrade ROM #1 RAID 0/1/10 for SCU (optional)
 Intel® C602 upgrade ROM #2 SAS RAID 0/1/10/5 for SCU (optional)
Management Net-
work
(1) Dedicated Intel® 82574 GbE RJ45 port for onboard management
Integrated Graphics AST2300 (optional with 10G SFP+ mezzanine card)
Front I/O
 (1) USB port per node
 (1) OCP debug header per port
 (1) Dedicated Rj45 management port
 (1) Power button
 (1) Reset button
Operating Environ-
ment
 Gaseous Contamination: Severity Level G1 per ANSI/ISA 71.04-1985
 Ambient operating temperature range: -5C to +35C
 Operating and Storage relative humidity: 10% to 90% (non-condensing)
 Storage temperature range: -40C to +70C
 Transportation temperature range: -55C to +85C (short-term storage)
 Operating altitude with no de-ratings: 1,000m (3,300 feet)
Table 1: System Specifications (Continued)
