Hub Site Sync Chapter 8

WinLink 1000 User Manual Release 1.9.40 8-4

After closing the window you are offered a cautionary notice:

If you accept it, the change is effected immediately. Notice that each site can have a different

Tx Power setting.

Hub Site Sync

Here you can view the HSS status:

Caution

Changing the Tx Power will affect service quality. The same considerations

apply here as were noted in the Installation procedure on page 5-17.
