Radwin WinLink 1000 User Manual

A Little Terminology Chapter 1
WinLink 1000 User Manual Release 1.9.40 1-19
General
Where a term is defined or introduced for the first time, it is shown in Boldface. You will have
noticed this usage in the Terminology section above.
Software
The RADWIN Manager is a Microsoft Windows application following the user interface con-
ventions of familiar Microsoft Windows programs.
We would describe the chain of menu commands indicated in the navigation example of
Figure like this,
Tools|Active Alarms|1 A
using Boldface for the menu labels and vertical bars to separate them.
Menu navigation in the RADWIN Manager
Similarly, mouse click items will be referred to like this:
“Click Next to continue.”
(A mouse click always uses the left mouse button unless stated otherwise.)
Windows Terminology
Look at Figure 1-1 above. The main application display which you see consists of a frame-
window with a menu bar, system icons and content. It will be referred to as a window, the
main window or the Manager window depending on context.
The top line of icons is the tool bar, and provides part of the menu bar functionality with a
mouse click.
At the bottom of the window is the status bar, a line of icons and text boxes.
The central part of the main window consists of several panes: On the right, there are Radio
Interference, Ethernet Service and the Frequency panes. The left hand pane (with the blue
background) is split into three sub-panes.
Caution
A Caution is a notification of risk of damage to equipment or of service
degradation
Warning
A Warning is a notification of risk of danger to persons operating near the
equipment
