Radwin WinLink 1000 User Manual

Link Compatibility Chapter 9
WinLink 1000 User Manual Release 1.9.40 9-2
The following table lists link and system information that can be monitored.
 To get diagnostics
1. From the Help menu, choose Get Diagnostics Information.
Figure 9-1: Get Diagnostics Dialog Box
2. Select or deselect the data options. If the file is to be sent to RADWIN Customer Sup-
port leave all options checked.
3. Click File Path to specify the folder in which you want to save the file and then click
Start to save the information.
The file is saved in the specified folder as Diagnostics Information.txt
Link Compatibility
Link Compatibility indicates the version compatibility using software traps. As new hardware
or software is added to existing networks compatibility issues may arise. An incompatibility
issue is indicated to the user by a change of color of the Link Status box on the Main Menu
Table 9-1: Get Diagnostics Data and Description
Data Description
System Data General information about the system
Link Information Information about the link properties
Events Log
• List of system events including those from other sites if this
site is defined as the trap destination
• Last 256 events from both sites
Site Configuration Data about the site parameters
Active Alarms List of active alarms
Performance Monitor Network performance data over defined time periods
Monitor Detailed event data record
