Antenna Characteristics
An antenna is the radiating and receiving element from which the radio signal, in the form of
RF power, is radiated to its surroundings and vice versa. The transmission range is a function
of the antenna gain and transmitting power. These factors are limited by country regulations.
The WinLink 1000 may be operated with an integrated antenna attached to the ODU unit, or
with an external antenna wired to the ODU via a N-type connectors. All cables and connec-
tions must be connected correctly to reduce losses. The required antenna impedance is 50.
FCC
Designed to meet 47 CFR Class B, Part15, Subpart B
ETSI
Designed to meet EN 300 386 V1.3.3; EN 301 489-4 V1.3.1; EN 301 489-1
CAN/CSA-CEI/IEC
Designed to meet CISPR 22-02
AS/NZS
Designed to meet CISPR22: 2006 Class B
Table A-1: Antenna Specifications
Freq range
GHz
Frequency bands
Form
factor
Type
Gain
dBi
Beam
width
Dimen-
sions
ft
2.3
GHz
2.4
GHz
2.5
GHz
2.7
GHz
4.9
GHz
5.3
GHz
5.4
GHz
5.8
GHz
5.9
GHz
6.0
GHz
2.40-2.70 Integrated Flat panel 16 20 1
2.30-2.70 Integrated Flat panel 17.5 25 1
4.94-6.00
Integrated Flat panel
18.5
10° 1
22
5.15-5.875 External Flat panel 18 18° 1
4.90-5.35 External Flat panel 21 9 1
5.15-6.02 External Flat panel
22 9 1
28 4.5 2
2.7-2.9 External Flat panel 17 °1
5.72-5.85 External Dish 29 6° 2
5.725-5.850 External Dish 32 6° 3
5.470-5.725 External Dish 31.5 4 3
4.90-5.10 External Dish 27 8° 2
4.90-6.00 External Dish 29 8° 2
5.250-5.35 External Dish 31 5° 3
5.470-5.725 External Dish 31.5 4 3
2.50-2.70 External Grid 24
E:13
H:9
2 x 3
