User Port Connectors Appendix B
WinLink 1000 User Manual Release 1.9.40 B-2
User Port Connectors
LAN Port
The LAN 10/100BaseT interface terminates in an 8-pin RJ-45 connector, wired in accordance
to Table B-3.
LAN Port for PoE-8
When connecting the PoE-8 LAN port cable directly to PC, a crossed LAN cable,
terminated with RJ-45 connectors on both ends must be used, wired according to
Table B-4:
O-PoE to PC LAN Cable
When connecting the O-PoE ETH port cable directly to a PC, a crossed LAN CAT-5e, 4
twisted-pair 24 AWG STP, terminated with RJ-45 connectors on both ends must be
used. The pinout in Table B-4 applies here.
White/Brown 7 7
Brown 8 8
Table B-3: Fast Ethernet Connector Pinout
Function Signal Pin
Transmit Data (positive) TD (+) 1
Transmit Data (negative) TD (–) 2
Receive Data (positive) RD (+) 3
Receive Data (negative) RD (–) 6
Table B-4: Fast Ethernet Connector Pinout
Function Color PC
Ethernet (RxN) White/Green 3
Ethernet (RxT) Green 6
Ethernet (TxT) White/Orange 1
Ethernet (TxN) Orange 2
Table B-2: ODU/HSS Unit Connection Pinout (Continued)
Color
ODU
RJ-45
HSS UNIT
RJ-45
