First steps Chapter 4
WinLink 1000 User Manual Release 1.9.40 4-9
2. Enter the current password, and the new password.
3. Click OK to confirm.
First steps
At this point the main window of the RADWIN Manager should be displayed:
Figure 4-10: Opening RADWIN Manager window prior to installation - IDU-C and new style
IDU-E
Note
A valid log-on password must contain at least five characters excluding
SPACE, TAB, and any of “>#@|*?;.”
Note
For what follows, it is assumed that you have set the IP addresses of both
ODUs. For the purposes of illustration, we will use the following IP
addresses:
Our managing computer has its NIC set to IP address 192.168.2.100. The
log-on ODU is set to IP address 192.168.2.101 and the over-the-air ODU is
set to 192.168.2.102. The Subnet Mask for both sites is 255.255.255.0 and
the Default Gateway is left unset. We will maintain this arrangement
throughout the remainder of this manual.
Other defaults are shown in Table 4-4.
