Installation Chapter 5
WinLink 1000 User Manual Release 1.9.40 5-9
3. Click the check box if Automatic Channel Selection is required.
4. The Available Channels List contains all of the allowable channels for the link. Check
the channels that can be automatically selected.
Selecting a new channel causes the system quality to change. The Quality bar pro-
vides an indication of the link quality from No serv(ice) (red) to Ethernet + TDM
(green) as shown in the bottom of Figure 5-7 above.
5. Click Next.
Step 4, Hub Site Synchronization Settings
Figure 5-9: HSS Settings
The Synchronization Status dialog box displays the current status of each side of the link. See
Chapter 10 for instructions about installing and configuring collocated links. If you do not
require HSS, click Next.
Step 5, Services
The Services dialog appears:
Note
ACS is only supported for a Channel Bandwidth of 20 MHz.
