Setting the RADWIN Manager Language
In the dialog of Figure 9-20, you can set the RADWIN Manager interface language, where
other localizations are available.
Setting SNMP Parameters
Use these choices to set the SNMP monitoring interval and time-out. These are only signifi-
cant if you are using an SNMP based network management system.
Remote Power Fail Indication
Remote power fail indication indicates to one side that the other side has suffered a power
failure. The failed site sends a final trap indication about the power loss just before powering
off.
A “Dying-Gasp” circuit identifies the power failure at a minimum interval of 20 milliseconds
before the ODU or IDU powers off. During that interval a message notifying the power failure
is sent to opposite site. External alarm output number 4 indicates power failure at the oppo-
site site.
Troubleshooting
Use the following table to troubleshoot LED fault indications:
Table 9-7: LED fault indicators
LED Status Remedy
PWR Off Check that power is connected to the IDU
IDU Red Check that the IDU/ODU cable is properly wired and connected.
ODU Red Check that the IDU/ODU cable is properly wired and connected.
AIR I/F
Orange Complete the installation procedure from the RADWIN Manager
Red
Check the antenna alignment. Check that the radio configuration of both site A and
site B units are the same (Channel and Link ID).
SVC
Orange
Red
Off
Alarm detected at the Site B interface or Local or Remote loopback
Alarm detected at the Site A interface
Ethernet only IDU or E1/T1 not configured
HSS
Red
Orange
HSS not operational due to improper signal detection. This ODU is not transmitting
HSS is operational. One of the following conditions apply:
• This ODU is a master that is generating signals and detecting signals
• This ODU is a master that is generating signals but detected improper sig-
nals
• This ODU is a client “Continue Tx” but is not detecting signals
• This ODU is a client “Disable Tx” and is detecting signals from multiple
sources
All orange cases transmit.
STBY
Red
Orange
MHS mode Primary, Link state not active
MHS mode Secondary, Link state active
