VLAN Tagging for Ethernet Service: Configuration Chapter 14

WinLink 1000 User Manual Release 1.9.40 14-7

Figure 14-3: VLAN tag settings

The choices for Ingress Mode are -

Figure 14-4: VLAN: Ingress modes

The two choices correspond respectively to the two rows of Table 14-1. Choosing Tag

causes the VLAN ID and VLAN Priority fields to become available:

Note

If you are using a new style IDU-E, the SFP row will not appear.
