Instrument functions
R&S
®
LCX Series
106User Manual 1179.2260.02 ─ 02
4. In the binning menu, activate binning.
9
4
6
10
21 3
5
78
Figure 8-24: Binning measurement results window
1 = Measurement function indicator
2 = Settings softkey
3 = CSV file
4 = Counter
5 = Sorting characteristics
6 = End of measurement bin
7 = Out bin
8 = Unconfigured bin
9 = User-specified bins
10 = Histogram
The specific binning display shows the configuration parameters of the measure-
ment and the bins for sorting the measured components. A bar graph displays the
distribution of the measurement results graphically.
You can access the settings or reset the counter on the screen directly.
Binning........................................................................................................................ 107
Settings softkey...........................................................................................................107
<filename>.................................................................................................................. 107
Counter....................................................................................................................... 107
Primary - <param>...................................................................................................... 107
Secondary - <param>................................................................................................. 107
Bins............................................................................................................................. 107
└ EOM..............................................................................................................107
└ OUT.............................................................................................................. 107
└ --....................................................................................................................107
└ B1 to B6 (B8)................................................................................................ 107
Histogram....................................................................................................................108
Specific instrument functions
