Remote control commands

R&S

LCX Series

209User Manual 1179.2260.02 ─ 02

The configuration commands set the corrsponding register. They determine which sta-

tus changes of the R&S LCX cause changes in the status registers, see Chap-

ter 10.2.4.2, "Instrument-specific status operation register", on page 147.

Value range: Decimal values in the range 0 to 32767 (=2

-1)

STATus:OPERation:CONDition?......................................................................................209

STATus:OPERation:ENABle............................................................................................209

STATus:OPERation:NTRansition..................................................................................... 209

STATus:OPERation:PTRansition......................................................................................209

STATus:OPERation[:EVENt]?..........................................................................................209

STATus:OPERation:CONDition?

Queries the CONDition part of the operational status register.

Return values:

<CONDition> Condition bits in decimal representation.

Range: 1 to 65535

Usage: Query only

STATus:OPERation:ENABle <Enable_value>

Enables or queries the bits in the enable register for the Standard Operation Register

group.

Parameters:

<Enable_Value> Range: 1 to 65535

STATus:OPERation:NTRansition <Value>

Sets or queries the negative transition filter. If a bit is set, a 1 to 0 transition in the cor-

responding bit of the condition register causes a 1 to be written in the corresponding bit

of the status register.

Parameters:

<Value> Range: 1 to 65535

STATus:OPERation:PTRansition <Value>

Sets or queries the positive transition filter. If a bit is set, a 0 to 1 transition in the corre-

sponding bit of the condition register causes a 1 to be written in the corresponding bit

of the status register.

Parameters:

<Value> Range: 1 to 65535

STATus:OPERation[:EVENt]?

Queries the actions the instrument has executed since the last reading.

STATus subsystem
