Suffix:
<m>
.
The command affects all channels regardless of the indicated
channel number. The suffix can be omitted.
Parameters:
<DecimationMode> SAMPle | PDETect | HRESolution
SAMPle
Input data is acquired with a sample rate which is aligned to the
time base (horizontal scale) and the record length.
PDETect (Peak Detect)
Tthe minimum and the maximum of n samples in a sample inter-
val are recorded as waveform points.
HRESolution (High Resolution)
The average of n sample points is recorded as waveform point.
*RST: SAMPle
CHANnel<m>:ARIThmetics
<TrArithmetic>
Selects the method to build the resulting waveform from several consecutive acquisi-
tions of the signal.
Suffix:
<m>
.
The command affects all channels regardless of the indicated
channel number. The suffix can be omitted.
Parameters:
<TrArithmetic> OFF | ENVelope | AVERage | FILTer
OFF
The data of the current acquisition is recorded according to the
decimation settings.
ENVelope
Detects the minimum and maximum values in an sample interval
over a number of acquisitions.
AVERage
Calculates the average from the data of the current acquisition
and a number of acquisitions before. The number of used
acquisitions is set with ACQuire:AVERage:COUNt.
FILTer
Sets a low-pass filter with 3 dB attenuation at a configurable limit
frequency set with ACQuire:FILTer:FREQuency. The filter
removes higher frequencies from the channel signals.
*RST:
OFF
TIMebase:ROLL:ENABle <Roll>
Enables the roll mode.
