Return values:
<State> INComplete | OK | UNEXpstop | INSufficient | ADDifferent
INComplete
The frame is not completely contained in the acquisition.
OK
The frame is o.k.
UNEXpstop
The frame stop is unexpected.
INSufficient
The frame is insufficient.
ADDifferent
The frame is different.
Usage:
Query only
BUS<b>:I2C:FRAMe<n>:STARt?
Returns the start time of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<StartTime> Range: depends on sample rate and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:STOP?
Returns the end time of the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
Return values:
<EndTime> Range: depends on sample rate and time base
Default unit: s
Usage: Query only
BUS<b>:I2C:FRAMe<n>:ACCess?
Returns the transfer direction - read or write access from master to slave.
