Remote Commands Reference
R&S
®
RTC1000
276User Manual 1335.7352.02 ─ 02
Return values:
<StartTime> Range: depends on sample rate and time base
Default unit: s
Usage: Query only
BUS<b>:SPI:FRAME<n>:WORD<o>:STOP?
Returns the end time of the specified data word.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame.
<o> Selects the word number.
Return values:
<StopTime> Range: depends on sample rate and time base
Default unit: s
Usage: Query only
BUS<b>:SPI:FRAME<n>:WORD<o>:MISO?
BUS<b>:SPI:FRAME<n>:WORD<o>:MOSI?
Returns the data value of the specified word.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n)
<o> Selects the word number (1...m)
Return values:
<Data> Decimal value of the data word
Usage: Query only
13.16.4 SSPI Bus
BUS<b>:SSPI:CLOCk:SOURce.......................................................................................277
BUS<b>:SSPI:CLOCk:POLarity.......................................................................................277
BUS<b>:SSPI:DATA:SOURce.........................................................................................277
BUS<b>:SSPI:DATA:POLarity.........................................................................................277
BUS<b>:SSPI:BITime.....................................................................................................278
BUS<b>:SSPI:BORDer...................................................................................................278
BUS<b>:SSPI:SSIZe......................................................................................................278
Protocol Analysis
