13.5.2 Zoom
TIMebase:ZOOM:STATe................................................................................................ 214
TIMebase:ZOOM:SCALe................................................................................................ 214
TIMebase:ZOOM:TIME...................................................................................................214
TIMebase:ZOOM:POSition..............................................................................................214
TIMebase:ZOOM:STATe <ZoomState>
Switches the zoom window on or off.
Parameters:
<ZoomState> ON | OFF
*RST: OFF
TIMebase:ZOOM:SCALe <ZoomScale>
Defines the time base in the zoom diagram in seconds per division.
Parameters:
<ZoomScale> Scaling of the zoom time base in s/div depending on time base
and channel settings.
TIMebase:ZOOM:TIME <Time>
Defines the offset of the trigger point to the reference point of the zoom diagram.
Parameters:
<Time> *RST: 0
Default unit: s
TIMebase:ZOOM:POSition <Position>
Defines the position of the zoom reference point (the reference point of the zoom win-
dow) in relation to the reference point of original time base.
Parameters:
<Position> Value in %
Range: 0 to 100, depending on the zoom time base
*RST: 50
13.5.3 Markers (Timestamps)
TSTamp:SET.................................................................................................................215
TSTamp:NEXT.............................................................................................................. 215
TSTamp:PREVious........................................................................................................ 215
TSTamp:CLEar..............................................................................................................215
TSTamp:ACLear............................................................................................................215
