R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
198User Manual 1335.7352.02 ─ 02
Parameters:
<Unit> V | A
PROBe<m>:SETup:ATTenuation:MANual <ManualAttenuation>
Sets the attenuation or gain of the probe if the probe was not detected by the instru-
ment.
Suffix:
<m>
.
Selects the input channel (1, 2).
Parameters:
<ManualAttenuation> Range: 0.001 to 10000
*RST: 1
PROBe<m>:SETup:ATTenuation[:AUTO]?
Returns the attenuation of an automatically detected probe.
Suffix:
<m>
.
Selects the input channel (1, 2).
Return values:
<ProbeAttenuation> Range: 0.001 to 1000
Usage: Query only
13.4 Trigger
● General A Trigger Settings....................................................................................198
● Edge Trigger......................................................................................................... 201
● Width (Pulse) Trigger............................................................................................ 203
● Video/TV Trigger...................................................................................................204
● Pattern (Logic) Trigger.......................................................................................... 205
13.4.1 General A Trigger Settings
TRIGger:A:MODE.......................................................................................................... 199
TRIGger:A:LEVel<n>[:VALue]......................................................................................... 199
TRIGger:A:SOURce....................................................................................................... 199
TRIGger:A:TYPE........................................................................................................... 200
TRIGger:A:HOLDoff:MODE.............................................................................................200
TRIGger:A:HOLDoff:TIME...............................................................................................200
TRIGger:OUT:MODE..................................................................................................... 200
TRIGger:EXTern:COUPling.............................................................................................201
TRIGger:OUT:POLarity...................................................................................................201
TRIGger:OUT:PLENgth.................................................................................................. 201
Trigger
