Remote Commands Reference

R&S

RTC1000

174User Manual 1335.7352.02 ─ 02

TIMebase:REFerence <ReferencePoint>

Sets the reference point of the time scale (Time Reference) in % of the display. The

reference point defines which part of the waveform is shown.

See also: TIMebase:POSition

Parameters:

<ReferencePoint> Range: 10 to 90

*RST: 50

Default unit: %

13.3.3 Acquisition

AUToscale.................................................................................................................... 174

ACQuire:MODE............................................................................................................. 174

ACQuire:INTerpolate...................................................................................................... 175

ACQuire:AVERage:COUNt............................................................................................. 175

ACQuire:AVERage:COMPlete?....................................................................................... 175

ACQuire:WRATe............................................................................................................176

ACQuire:POINts[:VALue]?.............................................................................................. 176

CHANnel<m>:TYPE.......................................................................................................176

CHANnel<m>:ARIThmetics.............................................................................................177

TIMebase:ROLL:ENABle................................................................................................ 177

ACQuire:FILTer:FREQuency...........................................................................................178

ACQuire:POINts:ARATe?............................................................................................... 178

ACQuire:SRATe?...........................................................................................................178

ACQuire:STATe.............................................................................................................178

ACQuire:TYPE.............................................................................................................. 179

ACQuire:PEAKdetect..................................................................................................... 179

ACQuire:HRESolution.................................................................................................... 180

AUToscale

Performs an autoset process: analyzes the enabled channel signals, and obtains

appropriate horizontal, vertical, and trigger settings to display stable waveforms.

Usage:

Event

Asynchronous command

ACQuire:MODE <AcquisitionMode>

Selects the method of adding waveform points to the samples of the ADC in order to fill

the record length.
