R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
194User Manual 1335.7352.02 ─ 02
Parameters:
<Threshold Mode> TTL | ECL | CMOS | USER1 | USER2
TTL
TTL level, set to 1.4V
ECL
ECL level, set to -1.3V
CMOS
CMOS level, set to 2.5V
USER1
USER1 level, can be set with POD:THReshold:UDLevel<u>.
USER2
USER1 level, can be set with POD:THReshold:UDLevel<u>.
POD:THReshold:UDLevel<u> <Threshold Level>
Set the user-defined threshold for the pod.
Suffix:
<u>
.
Select the user setting. (USER1, USER2)
Parameters:
<Threshold Level> Threshold level in V.
Range: -2 to 8 V
POD:State <State>
Switches the Pod on or off.
Parameters:
<State> ON | OFF
*RST: OFF
POD:DATA?
Returns the data of the specified digital channel. To set the export format, use
FORMat[:DATA]. To set the range of samples to be returned, use POD:DATA:
POINts.
Return values:
<WaveformData> List of values according to the format settings.
Example:
FORM ASC,0
POD:DATA?
1,1,1,1,1,1,0,0,0,0,0,0,...
Usage: Query only
Acquisition and Setup
