Remote Commands Reference
R&S
®
RTC1000
301User Manual 1335.7352.02 ─ 02
TRIGger:A:CAN:ACKerror <AcknowledgeError>
Specifies the trigger on acknowledge error when trigger type is set to error, using
TRIGger:A:CAN:TYPE. An acknowledgement error occurs when the transmitter does
not receive an acknowledgment - a dominant bit during the Ack Slot.
Parameters:
<AcknowledgeError> ON | OFF
*RST: OFF
TRIGger:A:CAN:CRCerror <CRCerror>
Specifies the trigger on checksum error when trigger type is set to error, using
TRIGger:A:CAN:TYPE.
Parameters:
<CRCerror> ON | OFF
*RST: OFF
TRIGger:A:CAN:FORMerror <FormError>
Specifies the trigger on form error when trigger type is set to error, using TRIGger:A:
CAN:TYPE. A form error occurs when a fixed-form bit field contains one or more illegal
bits.
Parameters:
<FormError> ON | OFF
*RST: OFF
TRIGger:A:CAN:BITSterror <BitStuffingError>
Specifies the trigger on stuff bit error when trigger type is set to error, using TRIGger:
A:CAN:TYPE.
Parameters:
<BitStuffingError> ON | OFF
*RST: ON
13.16.7.3 Decode
BUS<b>:CAN:FCOunt?.................................................................................................. 302
BUS<b>:CAN:FRAMe<n>:STATus?................................................................................ 302
BUS<b>:CAN:FRAMe<n>:STARt?...................................................................................303
BUS<b>:CAN:FRAMe<n>:STOP?................................................................................... 303
BUS<b>:CAN:FRAMe<n>:TYPE?....................................................................................303
BUS<b>:CAN:FRAMe<n>:DATA?................................................................................... 304
BUS<b>:CAN:FRAMe<n>:ACKState?..............................................................................304
BUS<b>:CAN:FRAMe<n>:CSSTate?...............................................................................304
BUS<b>:CAN:FRAMe<n>:DLCState?.............................................................................. 305
Protocol Analysis
