R&S RTC1000 - Bus<B>:Can:frame<N>:Bcount; Bus<B>:Can:frame<N>:Bseposition; Bus<B>:Can:frame<N>:Byte<O>:State

Remote Commands Reference
R&S
®
RTC1000
307User Manual 1335.7352.02 ─ 02
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<IdentifierValue> Decimal value
Usage: Query only
BUS<b>:CAN:FRAMe<n>:BSEPosition?
Returns the position of the bit stuffing error in the specified frame (if available).
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<ErrorPosition> *RST: 0
Default unit: s
Usage: Query only
BUS<b>:CAN:FRAMe<n>:BCOunt?
Returns the number of data bytes in the specified frame.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
Return values:
<ByteCount> Number of words (bytes)
Usage: Query only
BUS<b>:CAN:FRAMe<n>:BYTE<o>:STATe?
Returns the state of the specified data byte.
Suffix:
<b>
.
1, 2
Selects the bus.
<n> Selects the frame (1...n).
<o> Selects the byte number (1...n).
Protocol Analysis
