R&S RTC1000 User Manual

Remote Commands Reference
R&S
®
RTC1000
185User Manual 1335.7352.02 ─ 02
FORMat[:DATA] <DataFormat>,<Accuracy>
Defines the format for data export with
●
CHANnel<m>:DATA?
●
CHANnel<m>:DATA:ENVelope?
●
REFCurve<m>:DATA?
●
CALCulate:QMATh:DATA?
Parameters:
<DataFormat> ASCii | REAL | UINTeger | CSV
ASCii
List of values, for example, 1.23,1.22,1.24,..
<Accuracy> is 0 which means that the instrument selects the
number of digits to be returned. The query returns ASC,0.
REAL
Block data, 32 bit float values in 4 byte blocks.
<Accuracy> is always 32. The query returns REAL,32.
UINTeger
Unsigned integer format, binary values with length 8 or 16 bit
(UINT,8 or UINT,16). The data range for UINT,8 is 0 to 255, the
data range for UINT,16 is 0 to 65.535.
For data conversion, you need the results of following com-
mands:
...:DATA:XORigin?; ...:DATA:XINCrement?; ..:DATA:
Yorigin?; ...:DATA:YINCrement?; ...:DATA:
YRESolution?. .
CSV
Comma separated value list.
*RST:
ASC
<Accuracy> 0 | 8 | 16 | 32
Length of a data value in bit
*RST: 0
Example: Set the ASCII data format:
FORM ASC
Example: Query the data format:
FORM?
-> ASC,0
FORMat:BORDer <ByteOrder>
Defines the byte order for binary data export if FORMat[:DATA] is set to REAL or
UINT.
